Showing results 6 of total 431 | Page 1
- DN (mm): 15
- Pmax (bar): 16
- Drilling Standard: ANSI B16.5 Class 150
- Pipe Type: PE/PP
- Pipe OD (mm): 15
- D (mm): 98
- d1 (mm): 23
- d10 (mm): 22
- r1 (mm): 3
- k (mm): 60
- Holes (no.): 4
- d2 (mm): 16
- b1 (mm): 15
- DN (mm): 15
- Pmax (bar): 16
- Drilling Standard: EN1092 PN10
- Pipe Type: PE/PP
- Pipe OD (mm): 15
- D (mm): 98
- d1 (mm): 23
- d10 (mm): 22
- r1 (mm): 3
- k (mm): 65
- Holes (no.): 4
- d2 (mm): 14
- b1 (mm): 15
- DN (mm): 15
- Pmax (bar): 16
- Drilling Standard: EN1092 PN16
- Pipe Type: PE/PP
- Pipe OD (mm): 15
- D (mm): 98
- d1 (mm): 23
- d10 (mm): 22
- r1 (mm): 3
- k (mm): 65
- Holes (no.): 4
- d2 (mm): 14
- b1 (mm): 15
- DN (mm): 15
- Pmax (bar): 16
- Drilling Standard: ANSI B16.5 Class 150
- Pipe Type: PE/PP
- Pipe OD (mm): 20
- D (mm): 98
- d1 (mm): 28
- d10 (mm): 27
- r1 (mm): 3
- k (mm): 60
- Holes (no.): 4
- d2 (mm): 16
- b1 (mm): 15
- DN (mm): 15
- Pmax (bar): 16
- Drilling Standard: ANSI B16.5 Class 150
- Pipe Type: PVC
- Pipe OD (mm): 20
- D (mm): 98
- d1 (mm): 28
- d10 (mm): 27
- r1 (mm): 3
- k (mm): 60
- Holes (no.): 4
- d2 (mm): 16
- b1 (mm): 15
- DN (mm): 15
- Pmax (bar): 16
- Drilling Standard: EN1092 PN10
- Pipe Type: PE/PP
- Pipe OD (mm): 20
- D (mm): 98
- d1 (mm): 28
- d10 (mm): 27
- r1 (mm): 3
- k (mm): 65
- Holes (no.): 4
- d2 (mm): 14
- b1 (mm): 15
- Page 1 of total 72 pages
